"Remove water container and drip tray from machine. undo screw from seal using blade screwdriver. remover silicon seal from metal sieve. clean both seal and housing. fit new seal to sieve and refit to housing. do not overtighten."
BREW HEAD SEAL 4800/5800/5600/5400/3800/3600/3500
Location Ref:
Exploded diagrams, Schematics and other documents
Click on an image to enlarge the exploded view
Installation
Richard
YASS
"Remove brew head discard old seal and refit brew head with new one. replace on machine. do not over tighten screw. done"
Bert
NSW
"Unscrew screws and remove. fit back in reverse order."
Chris
SA
"Just had to remove the screw and replace the worn brew head seal."
Barbara
NSW
"Screw base on. coffee machine needs to be turned upside down and brewer head unsctrewed and seal replaced"
Anthony
VIC
"Unscrew steam wand replace o ring replace wand and tighten. for brew head seal remove mesh with phillips head screwdriver remove seal from mesh and replace ensuring it is on the correct way. replace mesh and tighten."
Ernest
QLD
"Simple - one screw removal, discard faulty seal, fit new seal, reassemble."
Michael
WA
"Replace"
Graham
NSW
"Refer to the user manual"
Ewold
NT
"Remove central bolt from brewhead"
